Pendulum load
The pendulum flatbed with aluminum sides and HARDOX bottom is developed for tough tasks where durability, flexible unloading and low dead weight are important. With pendulums at the rear and left side and a “Swedish” tailgate, you get a strong and functional solution for demanding contractor driving.
Internal dimensions
mm
Exterior dimensions
6,400 x 2,550 x 1,000 mm
Weight
2,500 kg
Benefits
The pendulum body is designed for efficient unloading, high wear resistance and flexible use in everyday life.
• HARDOX bottom for high wear resistance
• Aluminum sides for lower dead weight
• 180° pendulum on the left side for flexible unloading
• Pendulum in the rear for efficient emptying
• “Swedish” tailgate for practical and robust function
• Suitable for tough construction tasks
• Strong aluminum profiles for long service life
• Air-controlled pendulum for easy operation
Structure & standard equipment
The body is built with a focus on strength, functionality and efficient unloading.
• Pendulum body for wire hoist
• Sides and tailgate in anodized aluminum profiles
• Strong 60/40 aluminum sides
• Bottom in 5 mm HARDOX
• Swivel tailgate
• Top-hung aluminum side on the right side with bottom dropout
• 400 mm HARDOX air-controlled pendulum
• Ø160 mm rollers with nylon bushings
Additional equipment & customization
The pendulum body can be adapted to your work tasks and material types.
• Adaptation to hoist and vehicle
• Additional equipment as needed
• Individual solutions
• Adaptation to construction, earthmoving and material transport
Application
The pendulum body is particularly suitable for:
• Construction work
• Soil, sand and gravel
• Material transport
• Container and wire lifting tasks
• Tough daily tasks
Get a pendant light customized for your business
At MTDK we offer advice and tailor-made solutions so that you get the dropside truck that fits your needs exactly. We are happy to prepare a personal and non-binding offer – including attractive leasing and financing options.
